Source
Generating the 0% and 100% Values
1.
With the source value and measurement value displayed, press 0% or 100%.
The source value is set to the 0% or 100% value.
2.
Press OUTPUT ON/OFF. OUTPUT:OFF on the screen changes to OUTPUT:ON, and are
displayed 0% or 100% value is generated.
To turn off the source, press OUTPUT ON/OFF again.
Description
0% and 100% Values
Set the values within each source range.
These values become the divided source range or sweep source range.
2.7 Setting the 0% and 100% Values
2-17
IM CA500-01EN
2
