Description
Measurement Range (RTD Type)
Set the RTD type to use.
RTD Measurement Range
PT100 (PT100 JIS (3851)) -200.0°C to 800.0°C
JPT100 (PT100 former JIS (3916)) -200.0°C to 510.0°C
PT100 (3850) -200.0°C to 630.0°C
PT100 (3926) -200.0°C to 630.0°C
PT200 -200.0°C to 630.0°C
PT500 -200.0°C to 630.0°C
PT1000 -200.0°C to 630.0°C
Cu10 -100.0°C to 260.0°C
Ni120 -80.0°C to 260.0°C
PT50 -200.0°C to 630.0°C
PT50G -200.0°C to 800.0°C
PT100G -200.0°C to 630.0°C
Cu50M -180.0°C to 200.0°C
Cu100M -180.0°C to 200.0°C
Wiring Systems
You can select from 2W (two-wire), 3W (three-wire), and 4W (four-wire).
This setting is shared with resistance measurement.
3.5 Temperature Measurement Using RTDs
