5-2
IM CA500-01EN
Function2 Information
Saved data Notes
Source value
Function
Range
0% value
100% value
Temperature setting Thermocouple terminal setting TC-A/TC-B
TC-B RJC setting ON/OFF
Burnout setting ON/OFF
TC scale standard setting IPTS-68/ITS-90
Temperature unit °C
Frequency setting Amplitude voltage setting
Pulse count setting
TC measurement
settings
0% value
100% value
Contact output setting ON/OFF
CA550
You can save to a CSV file the date and time, the selected range, measurement value, and source
value when SAVE is pressed.
Number of Data Values and Files That Can Be Saved
The maximum number of data entries that can be saved in a single CSV file is 2000.
Data is saved to the same file until any of the following conditions is met.
• When the FUNCTION1 SETUP or FUNCTION2 SETUP is changed
• When the function or range of Function 1 and Function 2 is changed
• When the number of save data points exceeds 2000
• When the power is turned off
Up to 250 CSV files can be saved.
Data Format
The data save format is CSV.
You can save data to a PC through USB and open it using Excel or other PC software
applications.
The data separator is the symbol specified in section 6.4, “Setting the Decimal Symbol and
CSV Separator”.
File Name
The following file name is automatically assigned.
YYYYMMDDhhmmss_xx.csv
YYYYMMDDhhmmss: year, month, day, hour, minute, and second when the first data
entry was saved
YYYY: year, MM: month, DD: day, hh: hour, mm: minute, ss: second
xx: A sequence number starting from 00 that is assigned when the save date and time
overlaps
5.1 Saving Data Manually
To Next Page
