4-15
IM DL350E-17EN
Commands
1
2
3
4
5
App
Index
4.1 List of Commands
Command Function page
:DISPlay:GRATicule
Sets or queries the grid type. 4-100
:DISPlay:GROup<x1>?
Queries all display group settings. 4-100
:DISPlay:GROup<x1>:ACLear (All
Clear)
Clears all the trace assignments of the specified display group. 4-100
:DISPlay:GROUp<x1>:FORMat
Sets or queries the display format (the number of divisions in the vertical
direction) of the specified display group.
4-100
:DISPlay:GROup<x1>:TRACe<x2>?
Queries all source waveform settings for a display group. 4-100
:DISPlay:GROup<x1>:TRACe<x2>:SO
URce
Sets or queries the source that is assigned to the specified source waveform
of the specified display group.
4-100
:DISPlay:GROup<x1>:TRACe<x2>:ZN
UMber (Zone Number)
Sets or queries the zone number that displays the specified source waveform
of the specified display group.
4-100
:DISPlay:INTENsity:{CURSor|GRID
|MARKer}
Sets or queries the intensity of a display item. 4-100
:DISPlay:INTerpolate
Sets or queries the waveform interpolation method. 4-100
:DISPlay:LINDicator (Level
Indicator)
Sets or queries whether the right indicator on the T-Y waveform display is
displayed.
4-101
:DISPlay:MAPPing
Sets or queries the waveform mapping mode for when the display format is
set to an option other than 1.
4-101
:DISPlay:SDGRoup (Select Display
Group)
Sets or queries the number of the display group that is displayed. 4-101
:DISPlay:SVALue (Scale VALUE)
Sets or queries the on/off status of the scale value display. 4-101
:DISPlay:TLABel (Trace LABEL)
Sets or queries the on/off status of the waveform labels. 4-101
EVENt Group
:EVENt?
Queries all event waveform settings. 4-102
:EVENt:MEVent:EXECute
Manually inserts an event. 4-102
:EVENt:MEVent:MODE (Manual
Event)
Sets or queries whether the event waveform’s manual events are displayed. 4-102
FFT Group
:FFT?
Queries all FFT settings. 4-103
:FFT:AVERage?
Queries all FFT averaging settings. 4-103
:FFT:AVERage:COUNt
Sets or queries the average count of linear averaging. 4-103
:FFT:AVERage:EWEight
Sets or queries the attenuation constant of exponential averaging. 4-103
:FFT:AVERage:MODE
Sets or queries the FFT averaging mode. 4-103
:FFT:AVERage:TYPE
Sets or queries the averaging domain. 4-103
:FFT:POINt
Sets or queries the number of analysis source points of the FFT windows. 4-103
:FFT:STARt
Sets or queries the analysis-source start point of the FFT windows. 4-103
:FFT:WAVeform<x>?
Queries all FFT window settings. 4-103
:FFT:WAVeform<x>:HAXis
Sets or queries an FFT window
’
s horizontal-axis display method.
4-103
:FFT:WAVeform<x>:HORizontal?
Queries all horizontal axis settings of FFT analysis. 4-103
:FFT:WAVeform<x>:HORizontal:CSP
an?
Queries all settings related to the center point and span of the horizontal axis
in FFT analysis.
4-103
:FFT:WAVeform<x>:HORizontal:CSP
an:CENTer
Sets or queries the center value of the horizontal axis in FFT analysis. 4-104
:FFT:WAVeform<x>:HORizontal:CSP
an:SPAN
Sets or queries the span of the horizontal axis in FFT analysis. 4-104
:FFT:WAVeform<x>:HORizontal:LRI
Ght?
Queries all settings related to the left and right edges of the horizontal axis in
FFT analysis.
4-104
:FFT:WAVeform<x>:HORizontal:LRI
Ght:RANGe
Sets or queries the range of the left and right edges of the horizontal axis in
FFT analysis.
4-104
:FFT:WAVeform<x>:HORizontal:MO
DE
Sets or queries the horizontal scale of FFT analysis. 4-104
:FFT:WAVeform<x>:MODE
Sets or queries whether an FFT window is displayed. 4-104
:FFT:WAVeform<x1>:SOURce
Sets or queries an FFT window’s FFT source channel. 4-104
:FFT:WAVeform<x>:STYPe (Sub
Type)
Sets or queries an FFT window’s analysis sub type. 4-105
:FFT:WAVeform<x>:TYPE
Sets or queries an FFT window’s analysis type. 4-105
:FFT:WAVeform<x>:UNIT
Sets or queries a unit string that is attached to FFT computation results. 4-105
:FFT:WAVeform<x>:VSCale?
Queries all FFT vertical scale settings. 4-105
:FFT:WAVeform<x>:VSCale:CENTer
Sets or queries the center value of the FFT window when the vertical scale is
set to Manual.
4-105
