YOKOGAWA DL350 - Page 41

4-14
IM DL350E-17EN
4.1 List of Commands
Command Function page
:CURSor:XY:HVERtical:DXDy:STATe
Setsorqueriestheon/offstateoftheΔX/ΔYdisplayoftheHorizontaland
vertical cursors of the X-Y display.
4-95
:CURSor:XY:HVERtical:DXDy:VAL
ue?
QueriestheΔX/ΔYvalueoftheHorizontalandverticalcursorsoftheX-Y
display.
4-95
:CURSor:XY:HVERtical:DYDx?
QueriesallΔY/ΔXsettingsoftheHorizontalandverticalcursorsoftheX-Y
display.
4-95
:CURSor:XY:HVERtical:DYDx:STATe
Setsorqueriestheon/offstateoftheΔY/ΔXdisplayoftheHorizontaland
vertical cursors of the X-Y display.
4-95
:CURSor:XY:HVERtical:DYDx:VAL
ue?
QueriestheΔY/ΔXvalueoftheHorizontalandverticalcursorsoftheX-Y
display.
4-95
:CURSor:XY:MARKer:FORM
Sets or queries the form of the marker cursors on the X-Y waveform. 4-95
:CURSor:XY:MARKer:M<x>?
Queries all marker cursor settings for the X-Y waveform. 4-96
:CURSor:XY:MARKer:M<x>:DT<y>?
QueriesallsettingsrelatedtotheΔTvaluebetweenthespecifiedmarker
cursors on the X-Y waveform.
4-96
:CURSor:XY:MARKer:M<x>:DT<y>:ST
ATe
SetsorquerieswhethertheΔTvaluebetweenthespecifiedmarkercursors
on the X-Y waveform is displayed.
4-96
:CURSor:XY:MARKer:M<x>:DT<y>:VA
Lue?
QueriestheΔTvaluebetweenthespecifiedmarkercursorsontheX-Y
waveform.
4-96
:CURSor:XY:MARKer:M<x>:POSition
Sets or queries a marker cursor’s time-axis-equivalent position on the X-Y
waveform.
4-96
:CURSor:XY:MARKer:M<x>:T?
Queries all time value settings for a marker cursor on the X-Y waveform. 4-96
:CURSor:XY:MARKer:M<x>:T:STATe
Sets or queries whether the time value for a marker cursor on the X-Y
waveform is displayed.
4-96
:CURSor:XY:MARKer:M<x>:T:VALue?
Queries the time value of a marker cursor on the X-Y waveform. 4-96
:CURSor:XY:MARKer:M<x>:TRACe
Sets or queries the source waveform that you want to measure using the
marker cursors on the X-Y waveform.
4-96
:CURSor:XY:MARKer:M<x>:X?
Queries all X-axis-value settings for a marker cursor on the X-Y waveform. 4-96
:CURSor:XY:MARKer:M<x>:X:STATe
Sets or queries whether the X-axis value for a marker cursor on the X-Y
waveform is displayed.
4-96
:CURSor:XY:MARKer:M<x>:X:VALue?
Queries the X-axis value of a marker cursor on the X-Y waveform. 4-97
:CURSor:XY:MARKer:M<x>:Y?
Queries all Y-axis-value settings for a marker cursor on the X-Y waveform. 4-97
:CURSor:XY:MARKer:M<x>:Y:STATe
Sets or queries whether the Y-axis value for a marker cursor on the X-Y
waveform is displayed.
4-97
:CURSor:XY:MARKer:M<x>:Y:VALue?
Queries the Y-axis value of a marker cursor on the X-Y waveform. 4-97
:CURSor:XY:TYPE
Sets or queries the cursor type on the X-Y waveform. 4-97
:CURSor:XY:VERTical?
Queries all vertical cursor settings for the X-Y waveform. 4-97
:CURSor:XY:VERTical:DX?
QueriesallsettingsrelatedtotheΔXaxisoftheverticalcursorontheX-Y
waveform.
4-97
:CURSor:XY:VERTical:DX:STATe
SetsorquerieswhethertheΔX-axisvaluebetweentheverticalcursorson
the X-Y waveform is displayed.
4-97
:CURSor:XY:VERTical:DX:VALue?
QueriestheΔX-axisvaluebetweentheverticalcursorsontheX-Ywaveform. 4-97
:CURSor:XY:VERTical:POSition<x>
Sets or queries a vertical cursor position on the X-Y waveform. 4-97
:CURSor:XY:VERTical:TRACe
Sets or queries the source waveform that you want to measure using the
vertical cursors on the X-Y waveform.
4-97
:CURSor:XY:VERTical:X<x>?
Queries all X-axis-value settings for a vertical cursor on the X-Y waveform. 4-98
:CURSor:XY:VERTical:X<x>:STATe
Sets or queries whether the X-axis value for a vertical cursor on the X-Y
waveform is displayed.
4-98
:CURSor:XY:VERTical:X<x>:VALue?
Queries the X-axis value between the vertical cursors on the X-Y waveform. 4-98
DISPlay Group
:DISPlay?
Queries all display settings. 4-99
:DISPlay:ACCumulate:MODE
Sets or queries the accumulated waveform mode. 4-99
:DISPlay:AGRoup (Auto Grouping)
You can also automatically reassign just the channels (CH, Math, and sub
channels) whose displays are turned on to Gr.1 to Gr.4 and DMM.
4-99
:DISPlay:CINFormation?
Sets or queries all channel information display settings. 4-99
:DISPlay:CINFormation:MODE
Sets or queries whether the channel information display is displayed. 4-99
:DISPlay:CINFormation:TYPE
Sets or queries the contents of the channel information display. 4-99
:DISPlay:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:COLor
Sets or queries a waveform color. 4-99
:DISPlay:COLor:BASecolor
Sets or queries the color theme (base color) of the screen. 4-99
:DISPlay:DECimation
Sets or queries the number of dots that are used on the dot display. 4-99
:DISPlay:FORMat
Sets or queries the display format (the number of divisions in the vertical
direction).
4-100
