4-13
IM DL350E-17EN
Commands
1
2
3
4
5
App
Index
4.1 List of Commands
Command Function page
:CURSor[:TY]:MARKer:M<x>:X:VAL
ue?
Queries the X-axis value of a marker cursor on the T-Y waveform. 4-92
:CURSor[:TY]:MARKer:M<x>:Y?
Queries all Y-axis settings for a marker cursor on the T-Y waveform. 4-92
:CURSor[:TY]:MARKer:M<x>:Y:STA
Te
Sets or queries whether the Y-axis value for a marker cursor on the T-Y
waveform is displayed.
4-92
:CURSor[:TY]:MARKer:M<x>:Y:VAL
ue?
Queries the Y-axis value of a marker cursor on the T-Y waveform. 4-92
:CURSor[:TY]:TYPE
Sets or queries the cursor type on the T-Y waveform. 4-92
:CURSor[:TY]:VERTical?
Queries all vertical cursor settings for the T-Y waveform. 4-92
:CURSor[:TY]:VERTical:DX?
QueriesallsettingsrelatedtotheΔXvalueoftheverticalcursorontheT-Y
waveform.
4-92
:CURSor[:TY]:VERTical:DX:STATe
SetsorquerieswhethertheΔXvaluebetweentheverticalcursorsontheT-Y
waveform is displayed.
4-92
:CURSor[:TY]:VERTical:DX:VALue?
QueriestheΔXvaluebetweentheverticalcursorsontheT-Ywaveform. 4-93
:CURSor[:TY]:VERTical:DY?
QueriesallsettingsrelatedtotheΔYvalueoftheverticalcursorontheT-Y
waveform.
4-93
:CURSor[:TY]:VERTical:DY:STATe
SetsorquerieswhethertheΔYvaluebetweentheverticalcursorsontheT-Y
waveform is displayed.
4-93
:CURSor[:TY]:VERTical:DY:VALue?
QueriestheΔYvaluebetweentheverticalcursorsontheT-Ywaveform. 4-93
:CURSor[:TY]:VERTical:JUMP
Moves the specified vertical cursor to the center of the specified zoom
waveform.
4-93
:CURSor[:TY]:VERTical:PERDt?
Queriesallsettingsrelatedtothe1/ΔTvaluebetweentheverticalcursoron
the T-Y waveform.
4-93
:CURSor[:TY]:VERTical:PERDt:STA
Te
Setsorquerieswhetherthe1/ΔTvaluebetweentheverticalcursorsonthe
T-Y waveform is displayed.
4-93
:CURSor[:TY]:VERTical:PERDt:VAL
ue?
Queriesthe1/ΔTvaluebetweentheverticalcursorsontheT-Ywaveform. 4-93
:CURSor[:TY]:VERTical:POSition
<x>
Sets or queries a vertical cursor position on the T-Y waveform. 4-93
:CURSor[:TY]:VERTical:TRACe
Sets or queries the source waveform that you want to measure using the
vertical cursors on the T-Y waveform.
4-93
:CURSor[:TY]:VERTical:X<x>?
Queries all X-axis-value settings for a vertical cursor on the T-Y waveform. 4-93
:CURSor[:TY]:VERTical:X<x>:STA
Te
Sets or queries whether the X-axis value for a vertical cursor on the T-Y
waveform is displayed.
4-93
:CURSor[:TY]:VERTical:X<x>:VAL
ue?
Queries the X-axis value of a vertical cursor on the T-Y waveform. 4-94
:CURSor[:TY]:VERTical:Y<x>?
Queries all Y-axis-value settings for a vertical cursor on the T-Y waveform. 4-94
:CURSor[:TY]:VERTical:Y<x>:STA
Te
Sets or queries whether the Y-axis value for a vertical cursor on the T-Y
waveform is displayed.
4-94
:CURSor[:TY]:VERTical:Y<x>:VAL
ue?
Queries the Y-axis value (measured value) of a vertical cursor on the T-Y
waveform.
4-94
:CURSor:WAIT?
While the instrument is waiting for the specified :CURSor command to finish,
it will wait the time specified by the :CURSor:WAIT? timeout period until it
begins processing the subsequent command.
4-94
:CURSor:XY?
Queries all cursor settings for the X-Y waveform. 4-94
:CURSor:XY:HORizontal?
Queries all horizontal cursor settings for the X-Y waveform. 4-94
:CURSor:XY:HORizontal:DY?
QueriesallsettingsrelatedtotheΔYaxisofthehorizontalcursorontheX-Y
waveform.
4-94
:CURSor:XY:HORizontal:DY:STATe
SetsorquerieswhethertheΔY-axisvalueofahorizontalcursorontheX-Y
waveform is displayed.
4-94
:CURSor:XY:HORizontal:DY:VALue?
QueriestheΔY-axisvalueofahorizontalcursorontheX-Ywaveform. 4-94
:CURSor:XY:HORizontal:POSition
<x>
Sets or queries a horizontal cursor position on the X-Y waveform. 4-95
:CURSor:XY:HORizontal:TRACe
Sets or queries the source waveform that you want to measure using the
horizontal cursors on the X-Y waveform.
4-95
:CURSor:XY:HORizontal:Y<x>?
Queries all settings related to the Y axis of the horizontal cursor on the X-Y
waveform.
4-95
:CURSor:XY:HORizontal:Y<x>:STA
Te
Sets or queries whether the Y-axis value of a horizontal cursor on the X-Y
waveform is displayed.
4-95
:CURSor:XY:HORizontal:Y<x>:VAL
ue?
Queries the Y-axis value of a horizontal cursor on the X-Y waveform. 4-95
:CURSor:XY:HVERtical:DXDy?
QueriesallΔX/ΔYsettingsoftheHorizontalandverticalcursorsoftheX-Y
display.
4-95
