4-12
IM DL350E-17EN
4.1 List of Commands
Command Function page
:CURSor[:TY]:DEGRee:DY:STATe
SetsorquerieswhethertheΔYvaluebetweentheanglecursorsontheT-Y
waveform is displayed.
4-89
:CURSor[:TY]:DEGRee:DY:VALue?
QueriestheΔYvaluebetweentheanglecursorsontheT-Ywaveform. 4-89
:CURSor[:TY]:DEGRee:JUMP
Moves the specified angle cursor to the center of the specified zoom
waveform.
4-89
:CURSor[:TY]:DEGRee:POSition<x>
Sets or queries an angle cursor position on the T-Y waveform. 4-89
:CURSor[:TY]:DEGRee:REFerence
<x>
Sets or queries the angle reference start (Ref1) or end (Ref2) point on the
T-Y waveform.
4-89
:CURSor[:TY]:DEGRee:RVALue
Sets or queries an angle cursor’s reference angle on the T-Y waveform. 4-89
:CURSor[:TY]:DEGRee:TRACe
Sets or queries the source waveform that you want to measure using the
angle cursors on the T-Y waveform.
4-89
:CURSor[:TY]:DEGRee:Y<x>?
Queries all measured-value settings for an angle cursor on the T-Y
waveform.
4-89
:CURSor[:TY]:DEGRee:Y<x>:STATe
Sets or queries whether the measurements of an angle cursor on the T-Y
waveform is displayed.
4-90
:CURSor[:TY]:DEGRee:Y<x>:VALue?
Sets or queries the measured value of an angle cursor on the T-Y waveform. 4-90
:CURSor[:TY]:HORizontal?
Queries all horizontal cursor settings for the T-Y waveform. 4-90
:CURSor[:TY]:HORizontal:DY?
QueriesallsettingsrelatedtotheΔYaxisofthehorizontalcursorontheT-Y
waveform.
4-90
:CURSor[:TY]:HORizontal:DY:STA
Te
SetsorquerieswhethertheΔY-axisvalueofahorizontalcursorontheT-Y
waveform is displayed.
4-90
:CURSor[:TY]:HORizontal:DY:VAL
ue?
QueriestheΔY-axisvalueofahorizontalcursorontheT-Ywaveform. 4-90
:CURSor[:TY]:HORizontal:POSitio
n<x>
Sets or queries a horizontal cursor position on the T-Y waveform. 4-90
:CURSor[:TY]:HORizontal:TRACe
Sets or queries the source waveform that you want to measure using the
horizontal cursors on the T-Y waveform.
4-90
:CURSor[:TY]:HORizontal:Y<x>?
QueriesallsettingsrelatedtotheΔY-axisvalueofthehorizontalcursoron
the T-Y waveform.
4-90
:CURSor[:TY]:HORizontal:Y<x>:ST
ATe
Sets or queries whether the Y-axis value of a horizontal cursor on the T-Y
waveform is displayed.
4-90
:CURSor[:TY]:HORizontal:Y<x>:VA
Lue?
Queries the Y-axis value of a horizontal cursor on the T-Y waveform. 4-90
:CURSor[:TY]:HVERtical:DYDx?
QueriesallΔY/ΔXsettingsofthehorizontalandverticalcursorsontheT-Y
waveform.
4-91
:CURSor[:TY]:HVERtical:DYDx:STA
Te
Setsorqueriestheon/offstateoftheΔY/ΔXdisplayoftheHorizontaland
vertical cursors of the T-Y waveform.
4-91
:CURSor[:TY]:HVERtical:DYDx:VAL
ue?
QueriestheΔY/ΔXvalueofthehorizontalandverticalcursorsontheT-Y
waveform.
4-91
:CURSor[:TY]:MARKer?
Queries all marker cursor settings for the T-Y waveform. 4-91
:CURSor[:TY]:MARKer:FORM
Sets or queries the form of the marker cursors on the T-Y waveform. 4-91
:CURSor[:TY]:MARKer:M<x>?
Queries all measurement parameter settings for the specified marker cursor
of the T-Y waveform.
4-91
:CURSor[:TY]:MARKer:M<x>:DX<y>?
QueriesallsettingsrelatedtotheΔXvaluebetweenthespecifiedmarker
cursors on the T-Y waveform.
4-91
:CURSor[:TY]:MARKer:M<x>:DX<y>:
STATe
SetsorquerieswhethertheΔXvaluebetweenthespecifiedmarkercursors
on the T-Y waveform is displayed.
4-91
:CURSor[:TY]:MARKer:M<x>:DX<y>:
VALue?
QueriestheΔXvaluebetweenthespecifiedmarkercursorsontheT-Y
waveform.
4-91
:CURSor[:TY]:MARKer:M<x>:DY<y>?
QueriesallsettingsrelatedtotheΔYvaluebetweenthespecifiedmarker
cursors on the T-Y waveform.
4-91
:CURSor[:TY]:MARKer:M<x>:DY<y>:
STATe
SetsorquerieswhethertheΔYvaluebetweenthespecifiedmarkercursors
on the T-Y waveform is displayed.
4-91
:CURSor[:TY]:MARKer:M<x>:DY<y>:
VALue?
QueriestheΔYvaluebetweenthespecifiedmarkercursorsontheT-Y
waveform.
4-91
:CURSor[:TY]:MARKer:M<x>:JUMP
Moves the specified marker cursor to the center of the specified zoom
waveform.
4-92
:CURSor[:TY]:MARKer:M<x>:POSiti
on
Sets or queries a marker cursor position on the T-Y waveform. 4-92
:CURSor[:TY]:MARKer:M<x>:TRACe
Sets or queries the source waveform that you want to measure using the
marker cursors on the T-Y waveform.
4-92
:CURSor[:TY]:MARKer:M<x>:X?
Queries all X-axis settings for a marker cursor on the T-Y waveform. 4-92
:CURSor[:TY]:MARKer:M<x>:X:STA
Te
Sets or queries whether the X-axis value for a marker cursor on the T-Y
waveform is displayed.
4-92
