4-25
IM DL350E-17EN
Commands
4
Command Function page
:SYSTem:LOGic:NFORmat (Numerical
Format)
Sets or queries the numeric display format of logic module data. 4-152
:SYSTem:MLANguage
Sets or queries the menu language. 4-152
:SYSTem:OVERview
Displays the system information. 4-153
:SYSTem:RCMode (Remote Control
Mode)
Sets or queries whether remote signals to stop measurements will be
ignored (ON) or not (OFF).
4-153
:SYSTem:SCALefont
Sets or queries the font size that is used for waveform labels and scale
values.
4-153
:SYSTem:SOITem (Scale On ITEM)
Sets or queries which scales are displayed. 4-153
:SYSTem:STORage:FORMat:EXECute
Formats the SD memory card. This is an overlap command. 4-153
:SYSTem:TPANel:CAL:ABORt
Aborts touch panel calibration. 4-153
:SYSTem:TPANel:CAL:EXECute
Executes touch panel calibration. 4-153
:SYSTem:USBKeyboard
Sets or queries the USB keyboard type. 4-153
TIMebase Group
:TIMebase?
Queries all time base settings. 4-154
:TIMebase:CHANnel<x>:SRATe?
Queries the sample rate of the specified channel. 4-154
:TIMebase:SOURce
Sets or queries the time base. 4-154
:TIMebase:SRATe
Sets or queries the sample rate. 4-154
:TIMebase:TDIV
Sets or queries the T/div value. 4-154
TRIGger Group
:TRIGger?
Queries all trigger settings. 4-155
:TRIGger:ACTion?
Queries all action settings. 4-155
:TRIGger:ACTion:BUZZer
Sets or queries whether a beep is sounded as an action. 4-155
:TRIGger:ACTion:FOLDer
Sets or queries whether a date folder is created when waveform data or
screen capture data is saved to the storage medium when an action is
executed.
4-155
:TRIGger:ACTion:HCOPy
Sets or queries whether the screen image is printed on the USB printer when
an action is executed.
4-155
:TRIGger:ACTion:IMAGe?
Queries all settings for saving screen captures as an action. 4-155
:TRIGger:ACTion:IMAGe[:MODE]
Sets or queries whether a screen capture is saved to the storage medium as
an action.
4-155
:TRIGger:ACTion:IMAGe:CDIRecto
ry
Sets or queries the current directory on the storage medium where screen
captures are saved to as an action.
4-155
:TRIGger:ACTion:IMAGe:DRIVe
Sets the storage medium that screen captures are saved to as an action. 4-155
:TRIGger:ACTion:IMAGe:PATH?
Queries the path on the storage medium where screen captures are saved
to as an action.
4-155
:TRIGger:ACTion:MAIL?
Queries all settings for sending email as an action. 4-156
:TRIGger:ACTion:MAIL:COUNt
Sets or queries the email transmission limit for when email is sent as an
action.
4-156
:TRIGger:ACTion:MAIL:MODE
Sets or queries whether email is sent as an action. 4-156
:TRIGger:ACTion:MODE
Sets or queries whether the action feature is used. 4-156
:TRIGger:ACTion:SAVE?
Queries all the settings related to saving data as an action. 4-156
:TRIGger:ACTion:SAVE[:MODE]
Sets or queries whether waveform data is saved to the storage medium as
an action.
4-156
:TRIGger:ACTion:SAVE:ASCii:MODE
Sets or queries whether waveform data is saved to the storage medium in
ASCII format as an action.
4-156
:TRIGger:ACTion:SAVE:BINary:MO
DE
Sets or queries whether waveform data is saved to the storage medium in
binary format as an action.
4-156
:TRIGger:ACTion:SAVE:CDIRectory
Changes the current directory on the storage medium that waveform data is
saved to as an action.
4-156
:TRIGger:ACTion:SAVE:DRIVe
Sets the storage medium that waveform data is saved to as an action. 4-156
:TRIGger:ACTion:SAVE:MATLab:MO
DE
Sets or queries whether waveform data is saved to the storage medium in
MATLAB format as an action.
4-156
:TRIGger:ACTion:SAVE:PATH?
Queries the path on the storage medium that waveform data is saved to as
an action.
4-157
:TRIGger:AND?
Queries all AND trigger settings. 4-157
:TRIGger:AND:CHANnel<x1>:BIT
<x2>
Sets or queries the state of the specified bit of the specified logic channel for
AND triggers.
4-157
:TRIGger:AND:CHANnel<x1>:SCHann
el<x2>:BIT<x3>
Sets or queries the state of the specified bit of the specified sub channel of
the specified logic channel for AND triggers.
4-157
4.1 List of Commands
To Next Page
