YOKOGAWA DL350 User Manual

4-26
IM DL350E-17EN
Command Function page
:TRIGger:AND:CHANnel<x>[:CONDit
ion]
Sets or queries the state of the specified channel of the specified logic
channel for AND triggers.
4-157
:TRIGger:AND:CHANnel<x1>:SCHann
el<x2>[:CONDition]
Sets or queries the state of the specified sub channel of the specified logic
channel for AND triggers.
4-157
:TRIGger:ATRigger?
Queries all condition A settings. 4-157
:TRIGger:ATRigger:CHANnel<x1>:B
IT<x2>
Sets or queries the state of the specified bit of the specified logic channel of
condition A.
4-157
:TRIGger:ATRigger:CHANnel<x1>:S
CHannel<x2>:BIT<x3>
Sets or queries the state of the specified bit of the specified sub channel of
the specified logic channel of condition A.
4-157
:TRIGger:ATRigger:CHANnel<x>[:C
ONDition]
Sets or queries the state of the specified channel of the specified logic
channel of condition A.
4-158
:TRIGger:ATRigger:CHANnel<x1>:S
CHannel<x2>[:CONDition]
Sets or queries the state of the specified sub channel of the specified logic
channel of condition A.
4-158
:TRIGger:ATRigger:CONDition
Sets or queries the achievement condition of condition A. 4-158
:TRIGger:BBETween?
Queries all B Between trigger settings. 4-158
:TRIGger:BBETween:TIME<x>
Sets or queries a pulse width for B Between triggers. 4-158
:TRIGger:BGTime?
Queries all B>Time trigger settings. 4-158
:TRIGger:BGTime:TIME
Sets or queries the pulse width for B>Time triggers. 4-158
:TRIGger:BLTime?
Queries all B<Time trigger settings. 4-158
:TRIGger:BLTime:TIME
Sets or queries the pulse width for B<Time triggers. 4-158
:TRIGger:BTOut?
Queries all B TimeOut trigger settings. 4-159
:TRIGger:BTOut:TIME
Sets or queries the pulse width for B TimeOut triggers. 4-159
:TRIGger:BTRigger?
Queries all condition B settings. 4-159
:TRIGger:BTRigger:CHANnel<x1>:B
IT<x2>
Sets or queries the state of the specified bit of the specified logic channel of
condition B.
4-159
:TRIGger:BTRigger:CHANnel<x1>:S
CHannel<x2>:BIT<x3>
Sets or queries the state of the specified bit of the specified sub channel of
the specified logic channel of condition B.
4-159
:TRIGger:BTRigger:CHANnel<x>[:C
ONDition]
Sets or queries the state of the specified channel of the specified logic
channel of condition B.
4-159
:TRIGger:BTRigger:CHANnel<x1>:S
CHannel<x2>[:CONDition]
Sets or queries the state of the specified sub channel of the specified logic
channel of condition B.
4-159
:TRIGger:BTRigger:CONDition
Sets or queries the achievement condition of condition B. 4-159
:TRIGger:DELay
Sets or queries the delay. 4-160
:TRIGger:EOA?
Queries all Edge On A trigger settings. 4-160
:TRIGger:EOA:CHANnel<x1>:BIT
<x2>
Sets or queries the state of the specified bit of the specified logic channel for
Edge On A triggers.
4-160
:TRIGger:EOA:CHANnel<x1>:SCHann
el<x2>:BIT<x3>
Sets or queries the state of the specified bit of the specified sub channel of
the specified logic channel for Edge On A triggers.
4-160
:TRIGger:EOA:CHANnel<x>[:CONDit
ion]
Sets or queries the state of the specified channel of the specified logic
channel for Edge On A triggers.
4-160
:TRIGger:EOA:CHANnel<x1>:SCHann
el<x2>[:CONDition]
Sets or queries the state of the specified sub channel of the specified logic
channel for Edge On A triggers.
4-160
:TRIGger:EOA:CONDition
Sets or queries the achievement condition for Edge On A triggers. 4-160
:TRIGger:MODE
Sets or queries the trigger mode. 4-160
:TRIGger:OR?
Queries all OR trigger settings. 4-161
:TRIGger:OR:CHANnel<x1>:BIT<x2>
Sets or queries the state of the specified bit of the specified logic channel for
OR triggers.
4-161
:TRIGger:OR:CHANnel<x1>:SCHanne
l<x2>:BIT<x3>
Sets or queries the state of the specified bit of the specified sub channel of
the specified logic channel for OR triggers.
4-161
:TRIGger:OR:CHANnel<x>[:CONDiti
on]
Sets or queries the state of the specified channel of the specified logic
channel for OR triggers.
4-161
:TRIGger:OR:CHANnel<x1>:SCHanne
l<x2>[:CONDition]
Sets or queries the state of the specified sub channel of the specified logic
channel for OR triggers.
4-161
:TRIGger:OR:EXTernal:TYPE
Sets or queries the type of external trigger that is used with OR triggers. 4-161
:TRIGger:OUT?
Queries all trigger output settings. 4-161
:TRIGger:OUT:PRATe (Pulse rate)
Sets or queries the pulse output rate for when the trigger output terminal
output type is 3 (Sample Pulse).
4-161
:TRIGger:OUT:TIME
Sets or queries the H-pulse interval that is used when the trigger output
terminal output type is 1 (Pulse).
4-161
:TRIGger:OUT:TYPE
Sets or queries the trigger output terminal output type. 4-162
:TRIGger:POSition
Sets or queries the trigger position. 4-162
:TRIGger:SIMPle?
Queries all simple trigger settings. 4-162
:TRIGger[:SIMPle]:EXTernal:SLO
Pe
Sets or queries the external trigger slope. 4-162
4.1 List of Commands
