YOKOGAWA DL350 User Manual

4-27
IM DL350E-17EN
Commands
1
2
3
4
5
App
Index
Command Function page
:TRIGger[:SIMPle]:HYSTeresis
Sets or queries the hysteresis for simple triggers. 4-162
:TRIGger[:SIMPle]:LEVel
Sets or queries the trigger level of the channel specified by
:TRIGger:SIMPle:SOURce for simple triggers .
4-162
:TRIGger[:SIMPle]:LOGic?
Queries all simple trigger (logic trigger) settings. 4-163
:TRIGger[:SIMPle]:LOGic:BIT
Sets or queries the bit that sets the trigger slope. 4-163
:TRIGger[:SIMPle]:LOGic:SLOPe
Sets or queries the slope for logic triggers. 4-163
:TRIGger[:SIMPle]:SLOPe
Sets or queries the trigger slope of the channel specified by
:TRIGger:SIMPle:SOURce for simple triggers .
4-163
:TRIGger:SIMPle:SOURce
Sets or queries the source for simple triggers. 4-163
:TRIGger:SOURce?
Queries all the settings of the trigger source for enhanced triggers. 4-163
:TRIGger:SOURce:CHANnel<x1>[:SC
Hannel<x2>]?
Queries all the settings of the specified channel’s trigger source for enhanced
triggers.
4-163
:TRIGger:SOURce:CHANnel<x1>[:SC
Hannel<x2>]:CENTer
Sets or queries the wave window trigger center for enhanced triggers. 4-163
:TRIGger:SOURce:CHANnel<x1>[:SC
Hannel<x2>]:HYSTeresis
Sets or queries the specified channel’s hysteresis for enhanced triggers. 4-163
:TRIGger:SOURce:CHANnel<x1>[:SC
Hannel<x2>]:LEVel
Sets or queries the specified channel’s level for enhanced triggers. 4-164
:TRIGger:SOURce:CHANnel<x1>[:SC
Hannel<x2>]:WIDTh
Sets or queries the wave window trigger width for enhanced triggers. 4-164
:TRIGger:SOURce:CHANnel<x1>[:SC
Hannel<x2>]:WWIDth
Sets or queries the wave window trigger width for enhanced triggers. 4-164
:TRIGger:TGTime?
Queries all T>Time trigger settings. 4-164
:TRIGger:TGTime:TIME
Sets or queries the pulse width for T>Time triggers. 4-164
:TRIGger:TIMer?
Queries all time trigger settings. 4-164
:TRIGger:TIMer:DATE
Sets or queries the date for time triggers. 4-164
:TRIGger:TIMer:INTerval
Sets or queries the trigger interval for time triggers. 4-164
:TRIGger:TIMer:TIME
Sets or queries the time for time triggers. 4-164
:TRIGger:TITime?
Queries all T1<T<T2 trigger settings. 4-165
:TRIGger:TITime:TIME<x>
Sets or queries the pulse width for T1<T<T2 triggers. 4-165
:TRIGger:TLTime?
Queries all T<Time trigger settings. 4-165
:TRIGger:TLTime:TIME
Sets or queries the pulse width for T<Time triggers. 4-165
:TRIGger:TOTime?
Queries all T<T1,T2<T trigger settings. 4-165
:TRIGger:TOTime:TIME<x>
Sets or queries the pulse width for T<T1,T2<T triggers. 4-165
:TRIGger:TYPE
Sets or queries the trigger type. 4-165
:TRIGger:WWINdow?
Queries all wave window trigger settings. 4-165
:TRIGger:WWINdow:CHANnel<x>
Sets or queries the state of the specified channel for wave window triggers. 4-165
:TRIGger:WWINdow:CHANnel<x1>:SC
Hannel<x2>[:CONDition]
Sets or queries the state of the specified channel for wave window triggers. 4-165
:TRIGger:WWINdow:FREQuency
Sets or queries the cycle frequency for wave window triggers. 4-166
:TRIGger:WWINdow:SYNC?
Queries all synchronization channel settings for wave window triggers. 4-166
:TRIGger:WWINdow:SYNC:HYSTeres
is
Sets or queries the hysteresis of the synchronization channel for wave
window triggers.
4-166
:TRIGger:WWINdow:SYNC:LEVel
Sets or queries the level of the synchronization channel for wave window
triggers.
4-166
:TRIGger:WWINdow:SYNC:TRACe
Sets or queries the synchronization channel for wave window triggers. 4-166
WAVeform Group
:WAVeform?
Queries all waveform data output settings. 4-167
:WAVeform:BITS?
Queries the bit length of the waveform data specified by the
:WAVeform:TRACe command.
4-167
:WAVeform:BYTeorder
Sets or queries the transmission byte order for data formats that are 2 bytes
or longer.
4-167
:WAVeform:DATaselect
Queries whether to query the waveform specified by the :WAVeform:TRACe
command using ACQ data or PP data.
4-167
:WAVeform:END
Sets or queries the end data point in the waveform specified by the
:WAVeform:TRACe command (the main waveform).
4-167
:WAVeform:FORMat
Sets or queries the transmission data format. 4-167
:WAVeform:LENGth?
Queries the total number of data points in the waveform specified by the
:WAVeform:TRACe command (the main waveform).
4-167
:WAVeform:MODule?
Queries the module of the waveform specified by the :WAVeform:TRACe
command.
4-168
4.1 List of Commands
