YOKOGAWA DY080 User Manual

4-18
IM 01F06A00-01E
4. BASIC OPERATING PROCEDURES
1 Device setup
2 PV [cr]
3 AO1 [cr]
4 Flow Span [cr]
5 Mode
4 Detailed setup
1 Characterize meter
2 PV unit
Online Menu
to be continued to next page
1 Nominal size[u/d] <E10>
2 Body type [u/d] <E20>
3 Sensor type
[u/d] <E30>
4 K-factor setup
5 Detector No. [r&w]
[u/d]
15mm [r&w sel]
25mm
40mm
50mm
80mm
100mm
150mm
200mm
250mm
300mm
400mm
Standatd [r&w sel]
High pressure
Low flow unit(1)
Low flow unit(2)
1 K-factor unit[u/d] <E40>
2 K-factor[r&w][u/d] <E41>
p/l [r&w sel]
p/gal
p/Impgal
1 Temp unit [u/d] <C30> (*5)
2 Process temp[r&w] [u/d] <C31>
3 Base temp[r&w] [u/d] <C32>
4 Pressure unit [u/d] <C33> (*7)
5
Process pressure[r&w] [u/d] <C34>
6 Base pressure[r&w] [u/d] <C35>
7 Deviation[r&w] [u/d] <C36>
8 STD/Normal unit [u/d] <C37> (*4)
9 Time unit [u/d] <C40> (*1)
10 End
Standatd [r&w sel]
High temperature
Low temperature
1 Fluid[#] [u/d] <C20>
2
Special unit[#] [u/d]<D40>
Liquid:Volume
Gas/Steam:Volume
Liquid:Mass
Gas/Steam:Mass
Gas:STD/Normal
1 Volumetric unit [u/d] <C22> (*2)
2 Time unit [u/d] <C40> (*1)
3 End
1 Density unit [u/d] <C25> (*6)
2
Process density[r&w] [u/d]<C26>
3 Mass unit [u/d] <C27> (*3)
4 Time unit [u/d] <C40> (*1)
5 End
No
Yes
1 Base unit[r] <D41>
2 User's unit[r&w] [u/d] <D42>
3
Conversion factor[r&w] [u/d]<D43>
4 End
<*1>
F040608_3.EPS
[r] : read
[cr] : continuous read
[w] : write
[u/d] : upload/download data
[sel] : select
[#] : method
{ } : Only for
Option code /MV
< > : Parameter No.
in display and BRAIN
Terminal
( ) : Related parameter
