<9. OPERATION OF ISC (Induvtive Conductivity)>
9-6
IM 12A01A02-01E 8th Edition : Oct. 01, 2015-00
Next
20
12
4
mA
15.00
New sensor?
“Yes” resets
sensor wellness data.
Yes
No
HOUSING ASSY:
Module Pdn No. 23456789
Software Revision 2.10
HART Device Revision 2
Next
Reset wellness data
HOLD
FAIL
Next
c.c.(factory) 1.880/cm
c.c.(adjusted) 1.880/cm
Temp.comp.1 NaCl
Temp.comp.2 None
Sensor Ohm 500.0 Ω
Next
Sesor wellness:
Cell constant
Heat cycle – – – –
Progress Time – – – –
Reset welness data
Next
2010/02/15 16:04:07
Last calibrated at
-------- ------
Calibration due at
-------- ------
Projected Calibration
>12months (no meaning)
Next
ISC module(sensor1):
Module Pdn No. S12345
Software Revision 1.10
Next
(Fig.9.7)
*: This screen is displayed only if the PH201G distributor is used and “PH201G” is selected in communication setup.
*
Figure 9.5 Detail display
n Current output mA
= current output in mA. The range and function of this mA output can be set in Commissioning →
Output setup → mA.
For details, see section 10.2.
n Contact status
This screen is displayed only if the PH201G distributor is used and “PH201G” is selected in
communication setup.
