<9. OPERATION OF ISC (Induvtive Conductivity)>
9-9
IM 12A01A02-01E 8th Edition : Oct. 01, 2015-00
n Read logbook
The FLXA202/FLXA21 has two types of logbook per sensor to store history information on
events, such as changed settings and calibrations.
By selecting one of the logbooks that you wish to check, you can retrieve and check this
information. Storage of history information on each event in a logbook or which logbook to use for
storage can be set up on the Congure logbook screen. For details, see section 10.4.
History information on events are automatically stored on the preset conditions.
In addition to this storing, following three messages can be manually stored in the logbook;
"Sensor washed by hand", "Module replaced", "Sensor replaced"
To store these messages, press
and select one of three messages from the Item on the
Memorandum screen. Its event date/time will be the time when a message is selected and
entered.
When a password for Commissioning is set on the passwords’ setup, pressing
requires
entering the password. (Refer to the section 10.5.3.)
Read Logbook:
logbook1-1
Memorandum:
Item
Sensor washed by hand
Enter?
No
logbook1-1 1/1
Memorandum:
Item
Sensor replaced
Enter?
No
2010/02/15 17:04
Sensor replaced
2010/02/15 15:15
Power on
Finish
2010/02/15 15:15
Power on
Finish
logbook1-1 1/1
** When storing message manually.
**
(Fig.9.5)
Sensor washed by hand
Module replaced
Sensor replaced
logbook1-1
logbook1-2
No
Yes
Figure 9.7 Detail display (continued)
9.5 Trend graphics
Pressing on the Zoom display changes the display to a graphical mode in which the
average measured value is shown on a time scale. The “Live” value is also digitally displayed in
a text box. The time scale (X-axis) and the primary value scale (Y-axis) are set in the “DISPLAY
SETUP” menu (Section 10.7.2).
ISC
