<1. INTRODUCTION AND GENERAL DESCRIPTION>
1-3
IM 12A01A02-01E 8th Edition : Oct. 01, 2015-00
1.1 Instrument check
Upon delivery, unpack the instrument carefully and inspect it to ensure that it was not damaged
during shipment. If damage is found, retain the original packing materials (including the outer
box) and then immediately notify the carrier and the relevant Yokogawa sales ofce.
n Checking the model and sufx code
l FLXA202
Make sure the model and sufx code on the nameplate afxed to the left side of the housing.
NOTE
Be sure to apply correct power to the unit , as detailed on the nameplate.
-D-B-D-AB-P1-P1
-A-N-LA-N-N/U/H6
Figure 1.3 Inside of the FLXA202 and example of nameplate
l FLXA21
Loosen four front panel screws of the FLXA21, open the panel to the left, and make sure the
model and sufx code on the nameplate afxed to the back side of the front panel agrees with
your order.
CAUTION
When you open the front panel, make sure the screws are completely out of the screw holes, and
then open the front panel slowly in order not to damage the threaded parts on the housing. If the
threaded parts are damaged and the screws cannot be tightened, the waterproof performance
will deteriorate.
NOTE
Be careful not to lose the four front panel screws.
1
PH
SC
ISC
DO
SENCOM
