Figure 1.4 Inside of the FLXA21 and example of nameplate
l Checking the accessories
Make sure the accessories in Table 1.1 are included.
Table 1.1 Accessories
Product Name Quantity Remark
Cable glands FLXA202 3 sets One rubber plug attachement.
FLXA21 Plastic
housing
3 or 4 sets 4 sets when 2 sensors are used.
One grommet for grounding attachement.
Stainless
steel housing
3 sets One rubber plug attachement.
pH analyzer Jumper 2 pcs/module
Grommet set 1 set/module
SENCOM
pH analyzer
Grommet 1
Option Bracket 1 set Option code /UM*, /U, /PM
Sun shade hood 1 set Option code /H6, /H7, /H8
Tag plate 1 Option code /SCT
Adapter for conduit
work
3 or 4 sets Option code /CB4, /CD4, /CF4
4sets when Plastic housing are used.
Instruction Manual (CD-ROM) 1 copy
Startup Manual 1 copy
Safety Precautions 1 copy
*: The universal mounting kit (/UM) contains the brackets for both /U and /PM options.
NOTE
Rule of The Serial Number is as follows.
The Serial Number is dened by nine (9) alphanumeric characters as follows.
X
1
X
2
Y
3
M
4
N
5
N
6
N
7
N
8
N
9
e.g. 92NA07704
X
1
X
2
: Production Site
Y
3
M
4
: Year/Month code
N
5
N
6
N
7
N
8
N
9
: Tracking number
