<10. COMMISSIONING OF ISC (Inductive Conductivity)>
10-2
IM 12A01A02-01E 8th Edition : Oct. 01, 2015-00
Table 10.1 Menu Structure and Default Values in “Commissioning”
Parameter Ref. sect.
Measurement setup Measurement 10.1.1
Congure sensor
Measuring unit 10.1.2
Cell constant (factory)
Temperature settings
Temp. element 10.1.3
Temp. compensation Compensation 10.1.4
Reference temp.
Method
Calibration settings Limits: Air adjust 10.1.5
c.c.
Timing: Step Range
Stabilization time
Calib.interval
Concentration Additional table 10.1.6
Unit for table
Sensor diag. settings Process time: 10.1.7
Heat cycle:
Dene heat cycle
Output setup mA 10.2
Output
Process parameter
Setup
Linear
0 % value
100 % value
Table
Burn
Damping time
Simulate Simulation perc.
Congure Hold
Error conguration 10.3
Logbook conguration 10.4
Advanced setup Settings 10.5.1
Tag 10.5.2
Passwords 10.5.3
Date/Time 10.5.4
Communication 10.5.5
HART
PH201G
Factory setup 10.5.6
Display setup Main display 10.6.1
Trend 10.6.2
Auto Return 10.6.3
Adjust contrast 10.6.4
MONITOR display 10.6.5
NOTE
All the parameters for the quick setup (underlined ones in Table 10.1) are crucial for
measurement. If you change any of them, other parameters may be initialized. For the
parameters that may initialize other values, see Appendix 3.
10.1 Measurement setup
This section describes how to set up various parameters relating to measurements.
Measurements are performed based on the measurement parameter setup.
