YOKOGAWA ROTAMASS Total Insight - 4.5 Mechanical specification

General Instruction Manual
Product specification
Mechanical specification
18 / 90
IM 01U10B00-00EN-R, 3rd edition, 2018-07-09
Remote type
4
6
7
7
9
10
3
1
21
3
8
5
1 Process connections
2 Terminal box
3 Cable entry for connecting cable
4 Display cover
5 Sensor connection cover
6 Back cover for inputs and outputs, and power supply
7 Blind plug
8 Inputs/outputs cable entry
9 Power supply cable entry
10 Connecting cable
4.5 Mechanical specification
Mechanical specifications are defined in the related General Specifications (GS):
see GS01U10B0␣␣-00␣␣-R
