General Instruction Manual
Installation
Sensor installation
30 / 90
IM 01U10B00-00EN-R, 3rd edition, 2018-07-09
NOTICE
Use of seal tape for installation
In case of process connection with internal thread NPT you have to use a seal tape for in-
stallation.
6.3.3 Installation Rotamass Nano (Option PD)
For the Rotamass Nano the sensor can be installed on a DN50 (2") pipe by using a
bracket and U-bolt assy (model code position 15, option PD).
NOTICE
The bracket contains vibration dampers, but for extreme cases of vibration stronger
damping arrangements may be necessary to ensure best performance.
Fig.24: 2" fixing device option /PD for Nano
