YOKOGAWA ROTAMETER RAMC

<APPENDIX 1. LIST OF PARAMETERS FOR EACH BLOCK OF RAMC>
A-9
All Rights Reserved. Copyright © 2006, Rota Yokogawa
IM 01R01B02-01E-E 5th edition October 01, 2020 -00
Abs.
Index
Parameter Sub-
Parameter
Label Data Type/
Structure
Read/
Write
Initial value Functional Description
90 HARD_REVISION HW Version OctetString R/- e.g. V1.00 Indicates transmitter's electronical
hardware version
91 PERCENT Flow Percent Float R/- - Indicates ow value in % of scale span
92 PERCENT_UNIT - Unsigned16 R/- 1342: % Fixed unit (%) of the percent indication
93 PRIMARY_VALUE - Float R/- - Indicates ow value in arc length of
scale
94 PRIMARY_VALUE
_UNIT
- Unsigned16 R/- 1013: mm Fixed unit (mm) of the pointer position
95 DEVICE_STATUS1 Event Overview 1 Unsigned8 R/- not active Indicates 1st part of event overview
96 DEVICE_STATUS2 Event Overview 2 Unsigned8 R/- 0x10: Power Failure
(active)
Indicates 2nd part of event overview
97 DEFAULT_
CHANNEL
Default Channel Unsigned16 R/- Det. by ordered
scale
Indicates the process variable (index)
selected for channel transfer
98 EEPROM_
REVISION
EEPROM Version Unsigned16 R/- Cal-EEPROM
(high byte): e.g.
0x07: 7
Adj-EEPROM
(low byte): e.g.
0x08: 8
Indicates the revision of Cal- and
Adj-EEPROM
99 STATUS_
HANDLING
Flow Status
Handling
Unsigned8 R/W 0: Normal Status
Handling
Disables upper and lower measurement
range violation events (5 % to 105 %).
100 SCALE_SPAN_
UNIT
- Unsigned16 R/- Det. by ordered
scale
Indicates the ow unit printed on the
scale
101 WTM_REVISION WT-MAG Type Unsigned8 R/- 30 Indicates the transmitter type
102 FBK_REVISION Module Version Unsigned8 R/- 30 Indicates the communication module
version
103 DISPLAY_
SELECT
Display Selection Unsigned8 R/W 1: Total Value Allows variable selection for local display
indication
104 OPER_DENSITY Density Float R/- Det. by ordered
scale
Indicates uid's density value
105 OPER_DENSITY
_UNIT
- Unsigned16 R/- Det. by ordered
scale
Congurated unit of uid's density
106 FLOAT_BLOCKING - Record R/- - Indicates and controls the oat blocking
function
FLOAT_BLOCK_
ON
Float Blocking On Unsigned8 R/- 0: Off Enables and disables functionality
FLOAT_BLOCK_
LIMIT
Float Blocking
Limit
Unsigned8 R/- 0: 5 % Sets lower limit value of supervision
range
FLOAT_BLOCK_
TIME
Float Blocking
Time
Unsigned8 R/- 0: Turbulent Flow Sets reaction time according to ow type
FLOAT_BLOCK_
AZ_ON
Float Blocking
AZ On
Unsigned8 R/- 0: Off Executes oat blocking autozero
107 FLOAT_BLOCK_
AUTOZERO
Float Blocking
Autozero
Float R/- 0.000 Indicates oat blocking autozero value
108 LOW_FLOW_
CUTOFF_UNIT
Low Flow Cutoff
Unit
Unsigned16 R/- Det. by ordered
scale
Indicates the unit of low ow cut-off
value
109 DEVICE_STATUS3 Event Overview 3 Unsigned8 R/- Det. by ordered
scale
0x01: Volume Flow
Passivated
0x02: Mass Flow
Passivated
Indicates 3rd part of event overview
111 OPER_ACT_TIME - Record R/- - Indicates the total powered operation
time
minutes Operation Time
(Minutes)
Unsigned8 R/- Delivery condition Duration in minutes (0 to 59)
hours Operation Time
(Hours)
Unsigned8 R/- Delivery condition Duration in hours (0 to 23)
days Operation Time
(Days)
Unsigned16 R/- Delivery condition Duration in days
112 OPER_SDW_
TIME
- Record R/- - Indicates the total powered operation
time before last power down
minutes Oper. Time Shadow
(Minutes)
Unsigned8 R/- Delivery condition Duration in minutes (0 to 59)
hours Oper. Time Shadow
(Hours)
Unsigned8 R/- Delivery condition Duration in hours (0 to 23)
days Oper. Time Shadow
(Days)
Unsigned16 R/- Delivery condition Duration in days
114 LONG_TAG Electr. Long Tag OctetString R/W Optionally det. by
ordered device
Indicates and changes transmitter's
Long Tag Number (32 characters)
230 VIEW_1 R/- n.a. Indicates a Prole dened parameter
preselection
