YOKOGAWA SSC60D User Manual

Table 6.2-1 Domain Numbers and Switch Positions
Domain number
DIP switch bit number
1 2 3 4 5 6 7 8
1 0 0 0 0 0 0 0 1
2 0 0 0 0 0 0 1 0
3 1 0 0 0 0 0 1 1
4 0 0 0 0 0 1 0 0
5 1 0 0 0 0 1 0 1
6 1 0 0 0 0 1 1 0
7 0 0 0 0 0 1 1 1
8 0 0 0 0 1 0 0 0
9 1 0 0 0 1 0 0 1
10 1 0 0 0 1 0 1 0
11 0 0 0 0 1 0 1 1
12 1 0 0 0 1 1 0 0
13 0 0 0 0 1 1 0 1
14 0 0 0 0 1 1 1 0
15 1 0 0 0 1 1 1 1
16 0 0 0 1 0 0 0 0
17 1 0 0 1 0 0 0 1
18 1 0 0 1 0 0 1 0
19 0 0 0 1 0 0 1 1
20 1 0 0 1 0 1 0 0
21 0 0 0 1 0 1 0 1
22 0 0 0 1 0 1 1 0
23 1 0 0 1 0 1 1 1
24 1 0 0 1 1 0 0 0
25 0 0 0 1 1 0 0 1
26 0 0 0 1 1 0 1 0
27 1 0 0 1 1 0 1 1
28 0 0 0 1 1 1 0 0
29 1 0 0 1 1 1 0 1
30 1 0 0 1 1 1 1 0
31 0 0 0 1 1 1 1 1
n
Setting the Station Number
Set the station number in the range of 1 to 64. T
o set a station number, set the DIP switches
as shown in the following table.
• Setting DIP switches
0: The switch is flipped down in the following diagram.
1: The switch is flipped up in the following diagram.
<6.2 Setting Control Bus Interface Card Station Address > 6-4
IM 32Q06C10-31E 4th Edition : Jan.30,2015-00
