1. Hardware Configuration and Names
of Components
This section explains the ProSafe-RS hardware configuration and names of components.
•
Safety Control Units (for V net) names and models:
Table 1-1 Safety Control Units (for V net)
Name Model
Standard Type Safety Control Unit (for V net, Rack Mountable Type) SSC10S-S
Wide Range Temperature Type Safety Control Unit (for V net, Rack Mountable Type) SSC10S-F
Duplexed Standard Type Safety Control Unit (for V net, Rack Mountable Type) SSC10D-S
Duplexed Wide Range Temperature Type Safety Control Unit (for V net, Rack Mount-
able T
ype)
SSC10D-F
• Safety Control Units (for Vnet/IP) names and models:
Table 1-2 Safety Control Units (for Vnet/IP)
Name Model
Standard Type Safety Control Unit (for Vnet/IP, Rack Mountable Type) SSC60S-S and
SSC50S-S
Wide Range Temperature Type Safety Control Unit (for Vnet/IP, Rack Mountable
T
ype)
SSC60S-F and
SSC50S-F
Duplexed Standard Type Safety Control Unit (for Vnet/IP, Rack Mountable Type) SSC60D-S and
SSC50D-S
Duplexed Wide Range Temperature Type Safety Control Unit (for Vnet/IP, Rack
Mountable T
ype)
SSC60D-F and
SSC50D-F
• Safety Node Unit (Rack Mountable Type) (Model: SNB10D)
•
Unit for Optical Bus Repeater Module (Rack Mountable Type) (Model: SNT10D)
• Input/Output Modules
• Peripherals of Input/Output Modules
In the nest of the safety control unit (also referred to as CPU node), both of the processor
modules and the input and output modules can be installed. The maximum number of safety
node units (also referred to as I/O nodes which are placed under the safety control unit) that
can be connected to a safety control unit are as follows:
• SSC60S/SSC60D: Up to 13
• SSC50S/SSC50D, SSC10S/SSC10D: Up to 9
The control bus for SSC10S/SSC10D is V net and for SSC60S/SSC60D and SSC50S/
SSC50D are Vnet/IP.
TIP
In this manual, safety control stations are named and differentiated as follows:
• SCS : Safety Control Station (any model)
• SCSP2 : Vnet/IP Safety Control Station (CPU Node: SSC60S/SSC60D)
• SCSP1 : Vnet/IP Safety Control Station (CPU Node: SSC50S/SSC50D)
• SCSV1 : V net Safety Control Station (CPU Node: SSC10S/SSC10D)
<1. Hardware Configuration and Names of Components > 1-1
IM 32Q06C10-31E 4th Edition : Jan.30,2015-00
