Table 6.8-1 Setting of DIP Switches for Domain Number Setting (SW1)
Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7 Bit 8
1 1 0 0 0 0 0 1
Parity MSB LSB
3. Set the DIP switches (SW2) for the station number on the VI702 as follows:
Table 6.8-2 Setting of DIP Switches for Station Number Setting (SW2)
Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7 Bit 8
0 0 0 0 0 0 0 1
Parity MSB LSB
4. Check that Bit 1 through Bit 4 of the DIP switches (SW4) for the Action Mode are all set to
the of
f position on the VI702.
5. Remove the cover of the computer.
6. Insert the VI702 in the corresponding slot and fix the card.
7. Put back the cover of the computer.
8. Do not connect the cable to either BUS1 or BUS2.
9. Put back the power cord of the computer.
10. Start the computer, and then go to BIOS setting panel instead of starting Windows. If the
Windows started, it is necessary to shutdown and switch off the computer, and start the
computer for BIOS setting again.
11. Wait for about a minute after BIOS setting panel appears.
12. Turn off the power of the computer. For safety, remove the power plug from the outlet.
13. Remove the VI702 from the slot.
SEE
ALSO
For more information about DIP switches , refer to:
6.7, “Setting the Vnet/IP Interface Card Station Address” on page 6-12
For more information about going to BIOS setting panel, refer to:
The instruction manual of the PC
n
Removal Procedure
1.
Turn off the power of the PC. For safety, remove the power plug from the outlet.
2. Disconnect the cables for both BUS1 and BUS2. There is no need to disconnect the ca-
bles from the Layer2 switch.
3. Remove the VI702 from the slot.
SEE
ALSO
For more information about installing Vnet/IP driver to the PC, refer to:
B3.3, “Configuring Network Settings” in Installation (IM 32Q01C50-31E)
<6.8 Installing the Vnet/IP Interface Card in a PC> 6-17
