YOKOGAWA SSC60D User Manual

LED display
1
2
3
4
DX ACT
STATUS
1 5 9 13
2 6 10 14
3 7 11 15
4 8 12 16
4 channels (SDV521, SDV526)
LED display close-up
DX ACT
STATUS
With signal cable
interface adapter
For pressure clamp terminal
block and MIL cable
1 5
2 6
3 7
4 8
8 channels (SDV531, SDV53A)
DX ACT
STATUS
16 channels (SDV144, SDV541)
Figure 1.4.2-1 External View of Digital Input/Output Module
Pressure clamp terminal
block for single configuration
Pressure clamp terminal block
for dual-redundant configuration
Connector cover
for MIL cable
Figure 1.4.2-2 External View of Terminal Blocks
<1.4 Input/Output Modules > 1-17
IM 32Q06C10-31E 4th Edition : Jan.30,2015-00
