n
DIN Rail Mountable T
erminal Board Design
l
SBA4D Design
CN1
CN2
1A 2A 3A 4A 5A 6A 7A 8A 9A 10A 11A 12A 13A 14A 15A 16A
1B 2B 3B 4B 5B 6B 7B 8B 9B 10B 11B 12B 13B 14B 15B 16B
Figure 1.5.3-6 SBA4D
l
SBT4D Design
CN1
CN2
1A 2A 3A 4A 5A 6A 7A 8A
1B 2B 3B 4B 5B 6B 7B 8B
9A 10A 11A 12A 13A 14A 15A 16A
9B 10B 11B 12B 13B 14B 15B 16B
17A 18A
17B 18B
Figure 1.5.3-7 SBT4D
l
SBR4D Design
CN1
CN2
1B 2B 3B 4B 5B 6B 7B 8B
1C 2C 3C 4C 5C 6C 7C 8C
9B 10B 11B 12B 13B 14B 15B 16B
1A 2A 3A 4A 5A 6A 7A 8A 9A 10A 11A 12A 13A 14A 15A 16A
9C 10C 11C 12C 13C 14C 15C 16C
Figure 1.5.3-8 SBR4D
l
SBD2D Design
CN1
CN2
1A 1B 2A 2B 3A 3B 4A 4B
POWER1
POWER2
FUSE1
250V 15A
FUSE2
250V 15A
READY
Figure 1.5.3-9 SBD2D
l
SBD3D Design
CN1
CN2
POWER1
POWER2
READY
1A 2A 3A 4A 5A 6A 7A 8A
1B 2B 3B 4B 5B 6B 7B 8B
FUSE1
250V T 10A
FUSE2
250V T 10A
Figure 1.5.3-10 SBD3D
<1.5 Accessories Related to Input/Output Modules > 1-24
IM 32Q06C10-31E 4th Edition : Jan.30,2015-00
