73
IM 01B08B02-01EN
List of Parameters
List of Parameters
Input and Output Data Display (I/O Data)
Parameter Name Setting and Display Range Unit
Factory Default Value
Display and Setting Conditions
for Controller Mode
User
Set-
tings
YS1500
(SINGLE)
YS1700
(PROG)
SINGLE
CAS
SELECT
PROG
X1 Analog input 1
-25.0 to 125.0
% -25.0 R R R R
X2 Analog input 2 % -25.0 R R R R
X3 Analog input 3 % -25.0 R R R R
X4 Analog input 4 % -25.0 R R R R
X5 Analog input 5/Direct input signal output % -25.0 R R R R
X6 Analog input 6 (Note 1) % -25.0 R R R R
X7 Analog input 7 (Note 1) % -25.0 R R R R
X8 Analog input 8 (Note 1) % -25.0 R R R R
Y1 Analog output 1 -20.0 to 106.3 % -20.0 R R R R
Y2 Analog output 2
-6.3 to 106.3
% -6.3 R R R R
Y3 Analog output 3 % -6.3 R R R R
Y4 Analog output 4 (Note 1) % -6.3 R R R R
Y5 Analog output 5 (Note 2) % -6.3 N/A N/A N/A R
Y6 Analog output 6 (Note 2) % -6.3 N/A N/A N/A R
DI01 DO01 Digital input 1/Digital output 1
0, 1
0 R R R R
DI02 DO02 Digital input 2/Digital output 2 0 R R R R
DI03 DO03 Digital input 3/Digital output 3 0 R R R R
DI04 DO04 Digital input 4/Digital output 4 0 R R R R
DI05 DO05 Digital input 5/Digital output 5 0 R R R R
DI06 DO06 Digital input 6/Digital output 6 0 R R R R
DI07 DO07 Digital input 7/Digital output 7 (Note 1) 0 R R R R
DI08 DO08 Digital input 8/Digital output 8 (Note 1) 0 R R R R
DI09 DO09 Digital input 9/Digital output 9 (Note 1) 0 R R R R
DI10 DO10 Digital input 10/Digital output 10 (Note 1) 0 R R R R
DO11 Digital output 11 0 N/A N/A N/A R
DO12 Digital output 12 0 N/A N/A N/A R
DO13 Digital output 13 0 N/A N/A N/A R
DO14 Digital output 14 0 N/A N/A N/A R
DO15 Digital output 15 0 N/A N/A N/A R
DO16 Digital output 16 0 N/A N/A N/A R
Note 1: This value is displayed only on YS1700 Basic type with expandable I/O, and it is always displayed in the programmable mode.
Note 2: Y5 and Y6 are not actual terminals. They are used as the inside registers.
