List of Parameters

PID Setting Display 1 (PID1)

Parameter Name Setting and Display Range Unit

Factory Default Value

Display and Setting Conditions

for Controller Mode

User

Set-

tings

YS1500

(SINGLE)

YS1700

(PROG)

SINGLE

CAS

SELECT

PROG

STC STC mode

OFF: STC is not operating DISP: STC values displayed only

ON: STC is operating ATSTUP: STC automatic start-up

OFF R R R R

PV1 Process variable 1 Equivalent to -6.3 to 106.3% in the engineering unit (Note 1) Engineering unit Undefined R R R R

SV1 Setpoint value 1 Equivalent to -6.3 to 106.3% in the engineering unit (Note 1) Engineering unit 0.0 R/W R/W R/W R/W

MV1 Manipulated output variable 1 (Note 2) -6.3 to 106.3 % -6.3 R R R R

DV1 Deviation variable 1 PV1-SV1 Engineering unit Undefined R R R R

CSV1 Cascade setting value 1 Equivalent to -6.3 to 106.3% in the engineering unit (Note 1) Engineering unit 0.0 R R R N/A

FF1 Feedforward input value 1 -100.0 to 200.0 % 0.0 R R N/A N/A

LOAD Current load factor for user program 0.0 to 2000.0 % 0.0 N/A N/A N/A R

TRK1 Output tracking input value 1 -6.3 to 106.3 % -6.3 R R R N/A

LDMAX Maximum load factor for user program 0.0 to 2000.0 % 0.0 N/A N/A N/A R

PB1 Proportional band 1 0.1 to 999.9 % 999.9 R/W R/W R/W R/W

TI1 Integral time 1 1 to 9999 s (second) 1000 R/W R/W R/W R/W

TD1 Derivative time 1 0 to 9999 (0:OFF) s (second) 0 R/W R/W R/W R/W

SFA1 Adjustablesetpointfilterα1 0.000 to 1.000 0.000 R/W R/W R/W R/W

SFB1 Adjustablesetpoingfilterβ1 0.000 to 1.000 0.000 R/W R/W R/W R/W

GW1 Non-linear control gap width 1 0.0 to 100.0 % 0.0 R/W R/W R/W R/W

GG1 Non-linear control gain 1 0.000 to 1.000 1.000 R/W R/W R/W R/W

PH1 High limit alarm setpoint for PV1 Equivalent to -6.3 to 106.3% in the engineering unit (Note 1) (Note 3) Engineering unit 106.3 R/W R/W R/W R/W

PL1 Low limit alarm setpoint for PV1 Equivalent to -6.3 to 106.3% in the engineering unit (Note 1) (Note 4) Engineering unit -6.3 R/W R/W R/W R/W

HH1 High-high limit alarm setpoint for PV1 Equivalent to -6.3 to 106.3% in the engineering unit (Note 1) (Note 3) Engineering unit 106.3 R/W R/W R/W R/W

LL1 Low-low limit alarm setpoint for PV1 Equivalent to -6.3 to 106.3% in the engineering unit (Note 1) (Note 4) Engineering unit -6.3 R/W R/W R/W R/W

DL1 Alarm setpoint for deviation variable 1 Equivalent to 0.0 to 106.3% in the engineering unit (Note 1) (Note 4) Engineering unit 0.0 R/W R/W R/W R/W

VL1 Velocity alarm setpoint for PV1 Equivalent to 0.0 to 106.3% in the engineering unit (Note 1) (Note 4) Engineering unit 0.0 R/W R/W R/W R/W

VT1 Velocity alarm time setpoint for PV1 1 to 9999 s (second) 1 R/W R/W R/W R/W

HYS1 Alarm hysteresis 1 Equivalent to 0.0 to 20.0% in the engineering unit (Note 1) (Note 6) Engineering unit 2.0 R/W R/W R/W R/W

MH1 High limit setpoint of MV1 -6.3 to 106.3 (Note 5) % 106.3 R/W R/W R/W R/W

ML1 Low limit setpoint of MV1 -6.3 to 106.3 (Note 5) % -6.3 R/W R/W R/W R/W

MR1 Manual reset 1 -6.3 to 106.3 % -6.3 R/W N/A N/A R/W

RB1 Reset bias 1 0.0 to 106.3 % 0.0 R/W R/W R/W R/W

PMV1 Preset output 1 (Note 7) -6.3 to 106.3 % -6.3 R/W R/W R/W R/W

Note 1: The engineering units set with the Engineering parameters, SCH1, SCL1, and SCDP1.

Note 2: MV (Manipulated output variable) can be set only with the MV operation key at the bottom of the front panel. MV will be displayed when the controller mode is set to cascade or selector.

Note 3: Alarm will not occur if set at a maximum value.

Note 4: Alarm will not occur if set at a minimum value.

Note 5: Be sure to set to MH1>ML1. In the cascade mode, MH1 and ML1 will be used as the setpoint for the loop 2. In the selector mode, MH1 and ML1 will be the same as MH2 and ML2.

Note 6: The HYS1 setting is effective on all alarms of PH1, PL1, HH1, LL1, and DL1.

Note 7: When the controller mode is set to the cascade/selector mode, PMV will be displayed.
