York YMC2 - FIGURE 2 - Form 1 and 2 Rigging with Side Spreader Bar; FIGURE 3 - Form 1 and 2 Rigging Without Side Spreader Bar

JOHNSON CONTROLS
16
FORM 160.84-N1
ISSUE DATE: 11/22/2016
SECTION 2 - RIGGING AND LIFTING
LD16719b
Lifting
Holes
Lifting
Holes
Lifting
Holes
Side
Spreader
Bar
90°+/-10°
FIGURE 2 - FORM 1 AND 2 RIGGING WITH SIDE SPREADER BAR
LD16719c
Lifting
Holes
Lifting
Holes
Lifting
Holes
65°
Min.
FIGURE 3 - FORM 1 AND 2 RIGGING WITHOUT SIDE SPREADER BAR
