JOHNSON CONTROLS
46
FORM 160.84-N1
ISSUE DATE: 11/22/2016
SECTION 4 - REASSEMBLY
O
VSD COOLING PIPING
CONNECTED AT UNION
WITHOUT SEDIMENT ACCUMULATOR
WITH SEDIMENT ACCUMULATOR
WITH SEDIMENT ACCUMULATOR & VALVE
LD17284
F
FIGURE 32 - VSD MOUNTING HARDWARE IDENTIFICATION
Refer to Table 14 on page 43 for the torque values.
