JOHNSON CONTROLS
72
FORM 160.84-N1
ISSUE DATE: 11/22/2016
SECTION 5 - DIMENSIONS, NOZZLE ARRANGEMENTS AND WEIGHTS
TABLE 21 - VSD WEIGHTS
M6 MOTOR
CHILLERS
VSD WEIGHT LBS (KG)
HYP0774XHC30B-46
2060
(935)
HYP1278XHC30B-46
3806
(1727)
TABLE 22 - COMPRESSOR WEIGHTS
M6 MOTOR
CHILLERS
COMPRESSOR WEIGHT LBS (KG)
M6C-295FAC
4298
(1950)
M6C-331FAC
4439
(2014)
TABLE 24 - REFRIGERANT & WATER WEIGHT
M6 MOTOR CHILLERS
EVAPORATOR CONDENSER
REFRIGERANT WEIGHT
LBS (KG)*
WATER WEIGHT
LBS (KG)**
EC3312 CB2912 1331 (605) 2863 (1299)
EC3314 CB3314 1626 (739) 3589 (1628)
EC3914
CB3314 1908 (867) 4232 (1920)
CB3914 2072 (942) 4892 (2220)
*Refrigerant weight based on maximum tube bundle.
** Water weight is the total water in both shells and for 150psi, 2-pass, compact water boxes.
M6 WEIGHTS
TABLE 23 - UNIT ASSEMBLY – PANELS, PIPING,
WIRING, ETC
M6 MOTOR
CHILLERS
UNIT ASSEMBLY
PANELS, PIPING,
WIRING, ETC.
WEIGHT LBS (KG)
M6C-295FAC
1300
(591)
M6C-331FAC
1300
(591)
