York YMC2 - Evaporator 150 & 300 PSI Marine Water Boxes; FIGURE 51 - Evaporator - Marine Water Boxes (1-Pass Nozzle Arrangements); FIGURE 52 - Evaporator - Marine Water Boxes (2-Pass Nozzle Arrangements); FIGURE 53 - Evaporator - Marine Water Boxes (3-Pass Nozzle Arrangements)

JOHNSON CONTROLS
64
FORM 160.84-N1
ISSUE DATE: 11/22/2016
SECTION 5 - DIMENSIONS, NOZZLE ARRANGEMENTS AND WEIGHTS
EVAPORATOR 150 & 300 PSI MARINE WATER BOXES
FIGURE 51 - EVAPORATOR - MARINE WATER BOXES (1-PASS NOZZLE ARRANGEMENTS)
LD14012
1-Pass Evaporator Nozzle Arrangements
In Out
Left End Right End
Right End Left End
FIGURE 52 - EVAPORATOR - MARINE WATER BOXES (2-PASS NOZZLE ARRANGEMENTS)
LD14013
2-Pass Evaporator Nozzle Arrangements
In Out
Lower Right End Upper Right End
Lower Left End Upper Left End
LD14015
LD14014
FIGURE 53 - EVAPORATOR - MARINE WATER BOXES (3-PASS NOZZLE ARRANGEMENTS)
3-Pass Evaporator Nozzle Arrangements
In Out
Right End Left End
3-Pass Evaporator Nozzle Arrangements
In Out
Left End Right End
