JOHNSON CONTROLS
144
SECTION 8 - MICROPANEL
Form 201.47-ICOM1
Issue date: 17/11/2022
Unit setup mode
setting
Mode to change Minimum Maximum Default
Voltage Code Any 380, 400, 460 460
Quick Start Any Disabled / Enabled Disabled
Discharge Pressure
Cutout
Any 275 psig
(18.96 barg)
325 psig
(22.40 barg)
300 psig
(20.69 barg)
Soft Shutdown Free Cooling is
Disabled
Disabled / Enabled Enabled
Update Software Any Disabled, USB, SD Disabled
***Data Logging Mode Any Disabled, Serial, SD, SERIAL / SD, USB, USB
/ SD
SD
Data Logging Time Any 1 30 1
Anti-Recycle Timer Quick Start is
Enabled
30 s 120 s 30 s
Economizer Transition Remote Evaporator is
Enabled
10.0 % 40.0 % 20.0 %
Skip Frequency 1 Any Disabled / Enabled Disabled
Skip Frequency 2 Any Disabled / Enabled Disabled
Skip Frequency 1 Low
Limit
Any 51 Hz 205 Hz 56 Hz**
Skip Frequency 1 High
Limit
Any 52 Hz* 206 Hz* 68 Hz**
Skip Frequency 2 Low
Limit
Any 54 Hz* 208 Hz* 88 Hz**
Skip Frequency 2 High
Limit
Any 55 Hz* 209 Hz* 100 Hz**
Input Current Limiting Any Disabled / Enabled Disabled
Input Current Range Input Current Limiting
is Enabled
100 AMPS 2000 AMPS 800 AMPS
Refrigerant Type Any R-134a or R-513A R-134a
Discharge Superheat
Safety Ignore
Frequency
Refrigerant Type is
R-513A
40 Hz 150 Hz 40 Hz
Chilled Liquid Cooling
Mode
Free Cooling is
Disabled
Water cooling glycol cooling Water cooling
0.0 °C 11.1 °C 2.7 °C
Suction Pressure
Sensor Failure Bypass
Time
Any 60 s 1800 s 60 s
High Ambient Restart
Frequency
GTS75 100 Hz Max Compressor
Speed
Maxi Compressor
Speed - 20 Hz
Not GTS75 Max Compressor
Speed – 20 Hz
Max Compressor
Speed – 20 Hz
Max Compressor
Speed - 20 Hz
Discharge Pressure
Rate Threshold
Any 10 psi/s 99 psi/s 99 psi/s
Harmonic Filter Any Disabled / Enabled Disabled
Opt Fan Low Oil Hold
Di󰀨
Any 15.0 psid 30.0 psid 15.0 psid
Evap Anti-Freeze
Pump
Any Disabled / Enabled Disabled
Table 26 - Setup mode programmable values (cont'd)
