SECTION 8 - MICROPANEL
JOHNSON CONTROLS
145
Form 201.47-ICOM1
Issue date: 17/11/2022
8
Unit setup mode
setting
Mode to change Minimum Maximum Default
Enhanced Fans Mini-
mum Fan Speed
Any 0 % 20 % 10 %
Extended Leaving
Chilled Liquid Setpoint
Any Disabled / Enabled Disabled
****Quarterly Service
Warning
Free Cooling is
Disabled
Disabled / Enabled Enabled
****Yearly Service
Warning
Free Cooling is
Disabled
Disabled / Enabled Enabled
****3 Year Service
Warning
Free Cooling is
Disabled
Disabled / Enabled Enabled
****5 Year Service
Warning
Free Cooling is
Disabled
Disabled / Enabled Enabled
****Replace Oil Filter
Warning
Free Cooling is
Disabled
Disabled / Enabled Enabled
YorkTalk Communica-
tion Protocol Type
Any YORKTALK2 or YORKTALK3 YORKTALK 3
Table 26 - Setup mode programmable values (cont'd)
Unit Setup Mode Messages
The following messages will be displayed for the Unit
Setup Mode in the order they appear. The first group of
displays relates to setup parameters that relate to unit
configuration and factory set points.
The following setup display is selectable as YES or
The following three setup OPTION displays are select-
keys according to the options installed on the chiller:
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
SYS 1 NUMBER OF COND FANS = X
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
SYS 2 NUMBER OF COND FANS = X
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
COMP 1 OPERATING HOURS = XXXXX
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
COMP 2 OPERATING HOURS = XXXXX
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
COMP 1 STARTS XXXXX
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
COMP 2 STARTS XXXXX
SETUP MODE CLEAR HISTORY BUFFERS?
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
The following setup option is used for setting a pro-
grammable delay after change of value of a remote in-
put. The remote input is ignored until the service timer
expires.
The following setup display is selectable as STAN-
The following setup OPTION display allows program-
ming of the type of fan control installed. This includes
STD STAGED, OPT STAGED, OPT VSD or OPT EN-
HANCED FANS.
SETUP MODE REMOTE TEMP RESET OPTION
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
SETUP MODE REMOTE CURRENT LIMIT OPTION
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
SETUP MODE SOUND LIMIT OPTION
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
REMOTE INPUTS SERVICE TIME = XXXX SEC
SETUP MODE RUN PERMISSIVE CONTROL
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
SETUP MODE CONDENSER FAN CONTROL
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
