5-7
Select number of data bits: Seven bit
1- Seven bit 2-Eight bit
Select parity: Odd
1-None 2-Even 3-Odd 4-Low 5-High
Select number of stop bits: One bit
1-One bit 2-Two bits
Select handshaking type: RTS/CTS
1-RTS/CTS 2-XON/XOFF 3-None
If you choose XON/XOFF, you will go one menu level deeper to enter or confirm XON and
XOFF values.
Enter XON character
> 17
Press [ENTER] to confirm.
Enter XOFF character
> 19
Press [ENTER] to confirm and return to RS-232 setup.
RS-232 setup 1-Baud 2-Data 3-Parity
4-Stop 5-Handshake 6-Configuration
If you press [6] for Configuration, you will see the following.
Select configuration: Non-multidrop
1-Non-multidrop 2-Multidrop
The configuration option allows operation in either a point-to-point environment or in a
multidrop environment with an address (ID) assigned to your 2700 SELECT unit(s). The
default configuration is Non-multidrop. If you press [2] for Multidrop, you will see the
following.
Enter node address
> 38
Either enter another address # or accept the default, then confirm with [ENTER]. The node
address is only used when networking 2700s in a multi-instrument system. The 2700 responds
only to commands prefixed with the ID matching the address assigned from this menu.
