3.1
Data Input.
Two data input screens are used throughout the tester’s setup and operation:
1. Numeric keypad screen — used to input values for the timer and limit elds.
2. Alpha-Numeric keypad screen — used in text elds
» Example: The Program Name Field.
Examples of each are shown below:
Fig. 4b. Alpha-Numeric Keypad Screen.
Fig. 4a. Numeric Keypad Screen.
!
To access: press desired data eld with your nger or stylus.
Press the SHIFT key to change case.
