7.2
Valve Cleaning.
Debris from test parts or dirty incoming air can be trapped in the 2-Way valve, holding
the valve in an open position.
The valve is accessed by loosening the knurled ring in the center of the valve count-
er-clockwise. Once separated the spider seal and spacer ring can be removed to inspect
the valve seat and surrounding area for debris. The spider seal could aslo hold debris.
The valve is re-assembled by placing the spider seal into the lower section of the valve
with the bottom facing the valve seat, followed by the spacer ring, and lastly the valve
coil is pressed into the lower section secured by the knurled ring.
