29
Zaxis Inc. LLC
801.264.1000
2442 South 2570 West
West Valley City, UT 84119
5.3
I/O Setup.
Binary Prgrammable Selection Bits
Each stored program can be selected by a digitl big pattern. Select the number of pro-
grams to be used by the I/O. This action will desable the program number select on the
front display and will always return to the program selected by the active inputs. For
example if a selector switch is wired for fteen tests (BCD 1, 2). If there are no active
bits the test displayed will be program 0.
Program Start Mode
There are three options to start.
Start on Input 1: Activating input 1 on the I/O connection will start the cycle. The
input starts the test on the trailing edge of the signal. This selection is the default, and
allows the start button to run initiate the test. (Input 1)
Start on Input 1&2 (Anti-tie): This option is used when an operator needs to be
clear of movement in the xture. Two separate switches must be contacted within
300msec of each other, one switch cannot be held closed while the other is triggered.
(Inputs 1 and 2)
Start on Input 2 (Anti-tie) & Start Button: This option has a condition to be met
before the test can proceed. Input 1 on the I/O connector must be held active before
the START button is pressed. Typical door interlock option. If the input is released
before the test ends, the test will abort. A typical application would be for a door switch
on a safety enclosure. (Input 1)
