Setting Test Pressure
To set the test pressure, place a master part or plug onto the test port.
1. Press the Test Pressure data eld with your nger or stylus and enter the test
pressure value on the numeric keypad screen.
2. Set the desired ± Pressure Tolerances.
3. Check the Valve On box.
4. The internal pneumatics will open to allow the pressure from the regulator out
to the front port.
5. The pressure sensor will show the current pressure in the Curr. Pressure data
eld.
6. Adjust the regulator until the specied pressure from the Test Pressure value
eld is achieved.
7. Uncheck the Valve On box when nished.
Parameters to USB
The parameters of test can be either saved to or loaded from an external USB plugged
into the USB port on the front of the tester.
