Setting Fixture Timers
To set the test pressure, place a master part or plug onto the test port.
1. Press the Pre-Test Op 1 data eld with your nger or stylus and enter your val-
ues with the numeric keypad screen.
b. A minimum value of 0.1 sec. must be entered in the data eld. This time is
the amount of time the output will be set prior to test start.
3. Press the Post-Test Op 1 data eld with your nger or stylus and enter your val-
ues with the numeric keypad screen.
a. Leaving the Post-Test Op 1 timer at zero will de-energize all valves at the end
of the test.
2. Under Hold Clamps on Fail, select the on or off radio buttons.
c. Select this option to keep the clamps in their test position and the fail indica-
tor LED will ash to alert the user of failure.
d. The user can acknowledge the failure by pressing the fail LED and the
clamps will then follow the original set release timer.
Output Results
Select the check boxes for USB or Ethernet, in conjunction with set Data Logging op-
tions (discussed in Data Logging section) to output the desired results to either a USB
drive or over Ethernet.
!
The Pass/Fail results sent out to the I/O will not be posted
until the failure has been acknowledged.
