Units of Measure — The Isaac can display pressure, ow, and time in several user-se-
lectable measurement units. Changing units of measure is made through the Setup
screen.
V
Valves — The Isaac contains modular solenoid valve blocks that direct the ow of air
(or other gas) through measurement circuits. The number, type, and arrangement of
valves in an Isaac tester can be customized for special applications.
Vent (Also called Dump or Exhaust) — The nal step in a test. The vent step is pri-
marily used as a safety to vent any pressure away from the operator before removal of
the test part. Disabling the Vent will not affect the test result. After the Isaac completes
a test, the vent valve is activated to open the product into the Isaac’s internal chamber.
If a vent step is not required (for instance if you want to unplug product to vent pres-
sure), set the Vent timer to 0.0 and uncheck the Auto box.
