4 CS4070 Scanner
Charging
Before using the CS4070 for the first time,
charge the battery using the micro USB cable
or a cradle until all four green charging LEDs
light. Charge time is approximately three hours
for a fully discharged battery.
Inserting the Battery
1. Insert the battery, bottom first, into the
battery compartment in the back of the
device. Ensure the charging contacts point
toward the bottom of the scanner.
2. Press the battery down into the battery
compartment until the battery release latch
snaps into place.
Removing the Battery
To remove the battery, pull the release latch
upward with one finger, and use a finger from
your other hand to pull back on the indent in the
bottom of the battery housing. The battery
rotates about the bottom edge and the latch
end of the battery pops up, enabling you to lift it
out from the sides.
