Zebra ET5X - Insert Tablet into Slot; ET5 X without Rugged Frame

Accessories 5 - 15
Figure 5-16 Install Insert in Slot
Insert Tablet into Slot
ET5X without Rugged Frame
1. Install insert into slot.
2. Align the two alignment holes on the bottom of the tablet with the two alignment pins in the slot.
Figure 5-17 Insert ET5X without Rugged Frame into Slot
