APPENDIX A SPECIFICATIONS
Technical Specifications
The following tables summarize the ET5X’s intended operating environment and general technical hardware
specifications.
ET5X
The following table summarizes the ET5X’s intended operating environment.
Table A-1 Technical Specifications
Item Description
Physical and Environmental Characteristics
Dimensions
8” Configuration
:
228 mm W x 150 mm H x 12.5 mm D
(9.0 in. L x 5.9 in. W x 0.5 in. H)
10” Configuration
:
(269 mm W x 181 mm H x 12.5 mm D)
10.6 in. L x 7.1 in. W x 0.5 in. H
Weight
8” Configuration
:
555 g (1.2 lbs)
10” Configuration
:
750 g (1.55 lbs)
Display
8” Configuration
:
8.3 in (diagonal) 1920 x 1200 WUVGA with backlight
10” Configuration
:
10.1 in (diagonal) 1920 x 1200 WUVGA with backlight
Touch panel Capacitive 10 point multi-touch
Keypad Options Virtual, Bluetooth or USB
