MC3300x Mobile Computer Quick Start Guide
26
5-Slot Ethernet ShareCradle
The 5-Slot Ethernet ShareCradle:
• Provides 9 VDC power for operating the mobile computer and charging the battery.
• Simultaneously charges up to five mobile computers.
Compatible with the following batteries (charging in a device):
• MC3300x 7000mAh PowerPrecision+ extended capacity battery
• MC33XX 5200mAh PowerPrecision+ high capacity battery
• MC33XX 2740mAh PowerPrecision+ standard capacity battery (MC3300x-R/S & MC33XX-R/S only)
Figure 28 5-Slot Ethernet ShareCradle
NOTE To function properly, ensure that the MC3300x handstrap, if attached, does not interfere with the charging
contacts when the MC3300x is inserted into a charging cradle.
1000 LED
100/10 LED
