Zebra MC3300X Series User Manual

MC3300x Mobile Computer Quick Start Guide
5
Back View
Figure 2 MC3300x-G Back View
6 Power Key Press to suspend and resume device. Provides the following options:
Power off - Turn off the device.
Restart - Reboot the device when software stops responding.
Screenshot - Takes a snapshot of the current screen.
7 Keypad Use to enter data and navigate on screen functions.
8 Scan Button Initiates data capture when a scan application is enabled.
Table 2 MC3300x-G Features - Back View
Number Item Function
10 Battery Provides power for operating the device.
11 Battery Release
Latch
Release the battery from the device.
12 Speaker Provides audio output for video and music playback.
Table 1 MC3300x-G Features - Front View (Continued)
Number Item Function
11
10
12
13
14
MN-003567-01EN_mc3300x-qsg-en.fm Page 5 Monday, June 22, 2020 8:37 PM

Zebra MC3300X Series Specifications

General

Operating Temperature	-4° F to 122° F/-20° C to 50° C
Storage Temperature	-40° F to 158° F/-40° C to 70° C
Processor	Qualcomm Snapdragon 660 octa-core, 2.2 GHz
Operating System	Android 10
Memory	3GB RAM, 32GB Flash
Connectivity	Bluetooth 5.0, NFC
Camera	13 MP rear camera (optional)
Drop Specification	Multiple 6 ft./1.8 m drops to concrete across operating temperature range
Sealing	IP64
Scanner	SE4770
Keypad Options	Numeric Keypad, Alpha-Numeric Keypad
