11
Applicator Interface Option/Maintenance Kit for ZT600 Series and ZT411/ZT421 Printers
Remove the Old Option Card or Cover Plate
5/8/19 P1086089-003
Remove the Old Option Card or Cover Plate
1. See Figure 9 to verify the slots that can be used for the various option cards.
Figure 9 • Option Card Locations (ZT600 Shown)
Are you replacing an existing option card?
1
1
2
3
4
5
2
3
4
6
1
Blank cover
2
Parallel port
3
Applicator interface
4
Ethernet
5
Wireless (only in this location)
6
Internal print server IPV4 (only in this location)
If… Then…
Yes Go to Remove the Old Option Card on page 12.
No Go to Remove the Cover Plate onpage13.
