Zebra ZT600 Series Installation Instructions

Applicator Interface Option/Maintenance Kit for ZT600 Series and ZT411/ZT421 Printers
Remove the Old Option Card or Cover Plate
12
P1086089-003 5/8/19
Remove the Old Option Card
1.
2.
3. See Figure 10. Remove the two option card mounting screws from the top or bottom
slots.
Figure 10 • Remove the Option Card (ZT600 Shown)
4. Slide the option card out of the printer.
5. Go to Install the New Applicator Interface onpage14.
Caution • Turn Off (O) the printer and disconnect it from the power source before
performing the following procedure.
Caution • Observe proper electrostatic safety precautions when handling
static-sensitive components such as circuit boards and printheads.
Connect yourself to an antistatic device.
1
Option card
2
Mounting screws (2)
1
2

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
