Zebra ZT600 Series Installation Instructions

Applicator Interface Option/Maintenance Kit for ZT600 Series and ZT411/ZT421 Printers
Applicator Interface Option
4
P1086089-003 5/8/19
Applicator Specifications
Output voltage selections • 0 volts
• 5 Vdc (+/- 10%) <= 1.0 Adc
• 24 volts (+/- 10%) <= 0.4 Adc
Set by the following SGD command:
! U1 setvar "device.applicator.voltage" "X"
where X is 0, 5, or 24 to indicate the desired voltage. The
printer must be power cycled before the setting takes effect.
Note • A high-voltage lockout jumper installed on the
applicator interface PCBA prevents the output from going
above 5V, even if the SGD is sent for 24V output. This
precaution prevents accidental damage to external
equipment. The jumper must be repositioned to allow for
24V operation. The default setting is for 5V operation.
Pull-up resistor on output 10K +/- 5%
Pull-up resistor on input 4.7K +/- 5%
Output signal current sink <= 7 mAdc
User-supplied voltage range when
output voltage set to 0V
0–24 volts

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
