Primovert Start-Up and Operation ZEISS
12/2014 415510-7244-001 19
3.1.8 Mounting UV Protection Plate onto
Primovert iLED
• Put the UV protection plate (Fig. 9/1) on the
Primovert fluorescence stand.
• Fix it with the screws (Fig. 9/2) on both sides.
1 UV protection plate
2 Screws
Fig. 9 Mounting UV protection plate onto
Primovert iLED
