ZEISS Technical Data Primovert
52 415510-7244-001 12/2014
Light Sources
Halogen lamp
Adjustability of light source
Color temperature at 6 V
Luminous flux
Average life
Luminous area
HAL 6 V, 30 W
continuous, from 1.5 to 6 V DC
2800 K
765 lm
100 h
1.5 x 1.5 mm
iLED illumination
Fluorescent illumination
Homogeneous filed illumination
Analogous brightness adjustment from
blue LED, peak wavelength 470 nm, LED risk group 2 according
to IEC 62471
20 mm
approx. 15 to 100 %
LED illumination
Constant, brightness-independent
color temperature
Homogeneous field illumination
Suitable for objectives with
magnifications of
Analogous brightness adjustment from
White light LED, LED risk group 2 according to IEC 62471
7000 K
20 mm diameter
4x to 40x
approx. 15 to 100 %
Optical/Mechanical Data
Stand with stage focusing drives
With coarse focusing drive
With fine focusing drive
Total stage lift
45 mm/rev.
0.5 mm/rev.
15 mm
Objective change manual via quadruple nosepiece
Objectives
infinity-corrected objective range of Primo class with W 0.8
mounting thread
Eyepieces
with field-of-view number 20
30 mm tube diameter
WF 10x/20 Br. foc.
Specimen stage
Dimensions (width x depth)
Specimen guide
Verniers with numerical and alphabetic
scale
Coaxial drive
fixed
200 x 239 mm
right side
X direction: numerical scale, readable from right to left
Y direction: alphabetic scale, readable in the mirror
right side
LD condenser 0.3 for V
4x to 40x, a = 72 mm
LD condenser 0.4 for V
4x to 40x, a = 55 mm
Primovert with binocular tube
Maximum field-of-view number
Interpupillary distance
Tube angle
Viewing height
Viewing port
20
adjustable from 48 to 75 mm
45°
350 to 390 mm
tube factor 1x
