51 Rev.A
Number Meaning
1
3
4
2
1
Split screen.
2
Turn-off instruction / visual turn information.
3
Current road.
4
Distance to manoeuvre.
FM TUNER
Principle of the FM tuner: Receivable radio stations can be played with the ZENEC UKW RDS tuner.
An integrated DSP provides a clearer sound with weaker stations by means of noise interference
masking. The radio stations can be stored in a station list.
Radio Data System RDS
RDS transmits digital additional information in the analogue VHF wavelength, e.g. the station
name, the traffic announcements and the alternative frequencies. With a transmitter with multiple
frequencies, an automatic changeover to the frequency with the best reception quality takes place if
necessary.
CALL UP FM RADIO SOURCE
Option 1: Call up the FM Tuner source via [Home] ➔ [Media Widget], which has to be set
beforehand using the source selection buttons < >. Tap on the main widget field / cover
display field to call up the FM Tuner source.
Option 2: Select ➔ “FM Radio source” via the app overview page. Tap the source symbol to
call up the FM Radio source.
Option 3: Tap on the tuner sensor button to call up the FM Radio source.
The last station to be played is played, and the station information such as the station
name / transmission frequency is displayed.
The last station to be played is played and the station information such as the station name /
transmission frequency is displayed.
Overview of important elements, symbols, operating and display fields on the station information
page:
Function Symbol Meaning
Station information
Station information page (FM Tuner standard page with
station information).
Frequency scale Frequency band and scale display.
Preset List of stored stations (station list).
FM settings FM radio basic settings.
FM / DAB
changeover
Tap to switch to the DAB+ tuner source.
